G21L is a Anti-Jamming Tracker. When the device detects the jamming signal, it will trigger a beep sound and immediately cut off fuel/power to lock the vehicle. When the jamming signal disappears, the device will restore fuel/power to the vehicle.In addi-tion, the device supports a variety of functions, such as remote door opening/closing and door status detection, making it the preferred anti-theft product for industries.
When the device detects the jamming signal, it will trigger a beep sound and immediately cut off fuel/power to lock the vehicle.
The GPS module provides precise real-time location data of en-route fleet vehicles as well as cargoes.
Immobilize a vehicle by cutting off its power source/fuel supply via an installed relay.
Lock / Unlock the Car Door can be remotely controlled through the platform (WhatsGPS).
Get instant alerts when an interruption of power supply is detected.
Constantly detect the ACC / Ignition status of the vehicle.
GNSS
| Positioning Mode | GPS, BDS, GLONASS, Galileo |
| Positioning Band | LI, BI |
| Positioning Precision | <2.5m CEP |
| Tracking Sensitivity | -160dBm |
| Capturing Sensitivity | -158dBm |
| Positioning Time | Avg.hot start <1s Avg.cold start <28s |
| Antenna Dimensions | 25mmx25mmx4mm |
Communication
|
Communication Standard
|
LTE Cat1
|
|
Communication Frequency
|
GL-Version: LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12/ B13/B18/B19/B20/B25/B26/B28/B66 LTE-TDD B34/B38/B39/B40/B41 GSM 850/900/1800/1900 MHz EU-Version: LTE-FDD B1/B3/B5/B7/B8/B20 GSM 900/1800 MHz LA-Version: LTE-FDD B1/B2/B3/B4/B5/B7/ B8/B28/B66 GSM 850/900/1800/1900 MHz CN-Version: LTE-FDD B1/B3/B5/B8 LTE-TDD B34/B38/B39/B40/B41 GSM 900/1800 MHz |
|
Max Output Power
|
23土2dBm
|
Operating
|
Operating Voltage
|
9-90V DC
|
|
Operating Current
|
60mA
|
|
Standby Current
|
5mA
|
|
Battery
|
300mAh
|
|
Memory Capacity
|
16MB+16MB
|
|
LED Indication
|
GPS(Blue), GSM(Green), Power(Red)
|
|
Card Slot
|
Nano SIM
|
Physical
| Dimensions |
98.5× 38 × 17mm
|
|
Weight
|
72g
|
Environment
|
Operating Temperature
|
-20℃~+75℃
|
|
Operating humidity
|
10%～85%RH
|
|
Protection Rating
|
IP67
|
